500ton Animal Mineral Salt Block Brick Licking Hydraulic Press Machine for Livestock[/caption]
|
Model |
YQ32-500T |
|
|
Liquid working pressure (Mpa) |
25 |
|
|
Main cylinder stroke (mm) |
500 |
|
|
Max opening height (mm) |
1615 |
|
|
Lifting cylinder (ton) |
100×2 |
|
|
Lifting cylinder stroke (mm) |
350 |
|
|
Working table size (mm) |
L-R(between columns) |
1200 |
|
F-B(side to side) |
1000 |
|
|
Descent speed (mm/s) |
300 |
|
|
Working speed (mm/s) |
12-24 |
|
|
Return speed (mm/s) |
210 |
|
|
Motor power (kw) |
22×2 |
|
|
Machine size (mm) |
1950x1000x5100 |
|
|
Machine weight (kg) |
16000 |
|
500ton Animal Mineral Salt Block Brick Licking Hydraulic Press Machine for Livestock Features:
1. The main structure of independent research and development, integrated production.
2. Hydraulic oil press machine Technology is mature, and requires continuous improvement, so in order to ensure that the press machine body structure close, strong compression, rigidity, high precision,Good sealing,hydraulic pump noise,hydraulic salt machine work is very stable and strong, long life and other excellent performance.
3. Full range of hydraulic salt press products can be freely customized production, salt brick size, density, weight can be adjusted.
4. Animal salt tablet mineral licking block hydraulic press machine with production speed, high density of finished products, forming a good effect and so on.
5. Hydraulic design, production process rigorous professional, excellence, quality aspects of the gate, the constant pursuit of technological progress, innovation.
6. Simple structure, easy to learn and use, good security, operation is very convenient.
7. Besides, we can provide moulds for you, make the automatic production come out, given the best service.
