The 315 ton hydraulic press is a common press equipment, suitable for the pressing process of metal materials, such as stamping, bending, forming, extrusion, thin plate stretching, and powder product pressing. It is also suitable for the hot pressing process of non-metallic materials such as resin manhole covers, PMC, salt licking bricks, bait blocks, and environmentally friendly bricks. Therefore, the 315 ton hydraulic press requires high technical, experience, and quality requirements from hydraulic press manufacturers. Below, we will introduce how much a 315 ton hydraulic press costs, including its structure, parameters, price factors, etc., to ensure that you can buy with confidence.
The nominal pressure of the 315 ton hydraulic press is 3150KN, which can be divided into four column, single column, frame, gantry, etc. according to the equipment structure. Hydraulic presses with different structures have different functions and uses, which also affect the manufacturing cost of the equipment, and naturally have certain differences in price. When purchasing a 315 ton hydraulic press, one should choose a specific model based on their actual situation and specific use.
| Project | 315t |
| Maximum liquid pressure （Mpa） | 25 |
| Slider stroke （mm） | 800 |
| Maximum opening height （mm） | 1250 |
| Table size （mm） | 1260X1200 |
| Down speed of empty range （mm / S） | 100 |
| Working speed （mm / S） | 6-15 |
| Return speed （mm / S) | 80 |
| Motor power（ kw） | 22 |
| Oil pump displacement (ml / R) | 80 |
| Jacking force (t) | 63 |
| Ejection stroke (mm) | 250 |
The 315 ton hydraulic press is a common press equipment, suitable for the pressing process of metal materials, such as stamping, bending, forming, extrusion, thin plate stretching, and powder product pressing. It is also suitable for the hot pressing process of non-metallic materials such as resin manhole covers, PMC, salt licking bricks, bait blocks, and environmentally friendly bricks. Therefore, the 315 ton hydraulic press requires high technical, experience, and quality requirements from hydraulic press manufacturers. Below, we will introduce how much a 315 ton hydraulic press costs, including its structure, parameters, price factors, etc., to ensure that you can buy with confidence.
The nominal pressure of the 315 ton hydraulic press is 3150KN, which can be divided into four column, single column, frame, gantry, etc. according to the equipment structure. Hydraulic presses with different structures have different functions and uses, which also affect the manufacturing cost of the equipment, and naturally have certain differences in price. When purchasing a 315 ton hydraulic press, one should choose a specific model based on their actual situation and specific use.
| Project | 315t-C |
| Maximum liquid pressure （Mpa） | 25 |
| Slider stroke （mm） | 800 |
| Maximum opening height （mm） | 1250 |
| Table size （mm） | 1260X1200 |
| Down speed of empty range （mm / S） | 100 |
| Working speed （mm / S） | 6-15 |
| Return speed （mm / S) | 80 |
| Motor power（ kw） | 22 |
| Oil pump displacement (ml / R) | 80 |
| Jacking force (t) | 63 |
| Ejection stroke (mm) | 250 |
Note: The technical parameters of the 315 ton three beam four column hydraulic press are for reference only. We can provide equipment customization services and provide you with detailed parameters and quotations for the 315 ton four column hydraulic press according to your requirements.
Regular large-scale hydraulic press manufacturers like Shandong Woda Heavy Machinery have reasonable prices and guaranteed quality. They strictly calculate prices according to customer parameters by professional technicians. You can rest assured to purchase. Shandong Woda Heavy Machinery Co., Ltd. sincerely welcomes everyone to come to the factory for inspection and testing.
